Mi3101N Indicator

Specifications:

  • 7 Bits 15mm LED display
  •  Isolated Digital Communication Interface, RS232 or RS485 can be selected
  • Three Calibration methods
  • 220V power supply
  • Working Temp: 0ºC ~40ºC
  • Aluminium Indicator – Table Mount / Panel Mount
  • Two Relay Outputs – Open Contact
  • Analogue Output : 4 – 20 mA
    0 – 20 mA
    0 – 5 V
    0 – 10 V
  • Modbus Compatible
  • Adjustable Baud Rate

Description

Mi3101N is a weighing indicator which is applies for an industrial control fields. It combines weight display and analogue signal together. Its signal transaction of former part adopts high-precise A/D converter with 24 bits, and the output of analogue signal adopts D/A converter with 16bits. Its shell is a small box made from aluminium, easily to be inserted into control cabinet. It can be widely used in cement, chemical and metallurgical industrial weighing systems.

PRODUCT INFORMATION SHEET DOWNLOAD:

Mi3101N Indicator
